IBM(Hardware) IBM Cloud Object Storage(ICOS)
Category | Manager | Accesser | Controller | Slicestor | Slicestor | Slicestor |
---|---|---|---|---|---|---|
Model | M3110 | A3110 | C3110 | Slicestor 12 | Slicestor 53 | Slicestor 106 |
CPU Cores | Single 8 | Single 12 | Single 8 | Same as Controller | Same as Controller | Same as Controller |
Memory | 96 GB | 192 GB | 96 GB | Same as Controller | Same as Controller | Same as Controller |
Disks Per Node | 2 Boot/OS | 2 Boot/OS | 2 Boot/OS | 12 | 53 | 106 |
Disk Type | 960 GB SSD | 480 GB SSD | 480 GB SSD | 4TB, 8TB, 12TB HDD | 4TB, 8TB, 12TB HDD | 4TB, 8TB, 12TB HDD |
Max Raw Capacity | 1,920GB | 960GB | 960GB | 144TB | 636TB | 1272TB |
Rack Units | 1U | 1U | 1U | 2U | 4U | 4U |
W / H / L | 436/43/762 | 436/43/762 | 436/43/762 | 483/88/630 | 441/176/1139 | 441/176/1139 |
Componentry
1 x Intel XEON Silver 4110 Processor
- 8 Cores
- 16 Threads
- Base Freq 2.10 GHz
96 GB Ram
- 6 x 16 GB 2666 DIMMs
2 x 960 GB OS/Boot Drive SSDs in Raid 1
- Broadcom MegaRAID 9361-41 Controller
2 x 10Gb Ethernet ports – integrated into chassis
- 2 x SFP+
Cloud Object Storage Software Release
- ClevOS Release 3.14.4 以上
Summation
- Manager designed to support up to 4,500 simultaneous appliances in a single Cloud Object Storage Network
1 x Intel XEON Gold 6126 Processor
- 12 Cores
- 24 Threads
- Base Freq 2.60 GHz
192 GB Ram
- 12 x 16 GB 2666 DIMMs
2 x 480GB OS/Boot Drive SSDs in Software RAID
2 x 10Gb Ethernet ports – integrated into chassis
- 2 x SFP+
Cloud Object Storage Software Release
- ClevOS Release 3.14.4 以上
Summation
- An Accesser Server that provides up to 15% more read and write performance (i.e. can complete up to 15% more reads and writes in the same timeframe) as the Accesser Server 3105
1 x Intel XEON Silver 4110 Processor
- 8 Cores
- 16 Threads
- Base Freq 2.10 GHz
96 GB Ram
- 6 x 16 GB 2666 DIMMs
2 x 480GB OS/Boot Drive SSDs in Software RAID
1 x Broadcom 9305-16i HBA controller used to manage Data Drives in attached Disk Enclosures
2 x 10Gb Ethernet ports – integrated into chassis
- 2 x SFP+
Cloud Object Storage Software Release
- Usable with any ClevOS Release 3.14.4 or greater
Summation
- Controller Node that when combined with a J10 (Small Disk Enclosure), forms a Slicestor12 and provides up to 10% more write performance (i.e. can complete up to more than 10% writes in the same time frame, than a Slicestor 2212A). It will perform at par with the Slicestor 2212A as it concerns reads, which is as expected as reads are disk bound, so the head node will not make much of a difference
- 2U Chassis (Small Disk Enclosure)
-
- HxWxD
3.5” x 19” x 24.8” / 88mm x 483mm x 630mm -
Weight
52.7 lbs / 26 kg (Max Weight Fully Loaded) - 12 Drives Slots to support hot-swap 3.5 (LFF) Data Drives
- 12G SAS Input/Output Module (IOM)
-
1+1 Redundant Power Cooling Modules (PCM)
580W Power Supply
Dual cooling fans integrated in each PCM
- HxWxD
- 4U Chassis (Medium and Large Disk Enclosure)
-
- HxWxD
6.95” x 17.4” x 44.8” / 176mm x 441mm x 1139mm - Weight – Without Drives
Without Drives – 99 lbs / 45 kg
Medium JBOD Fully Loaded 53 Drives – 194 lbs / 82 kg
Large JBOD Fully Loaded 106 Drives – 290 lbs / 141 kg - 106 Drive Slots to support hot-swap 3.5 (LFF) Data Drives
53 Usable in the Medium Disk Enclosure
106 Usable in the Large Disk Enclosure - Single or Dual 12G SAS Input/Output Module (IOM)
- 1+1 Redundant Power Canisters
2 x 2KW Power Supply Units - 4 x Removable Rear Fans
- Controller Fan Module
- Tool-Less Drive Carriers
- HxWxD
4TB/8TB/12TB HDDs Available
バケット名は、全てのアカウントを通じてユニークな値を設定する必要があります。
バケット数は最大100ですが、バケットあたりのオブジェクト数は無制限です。1オブジェクトの最大サイズは、10TBです。
https://www.ibm.com/jp-ja/cloud/object-storage/faq
Storage Class | Standard | Vault | Cold Vault | Smart Tier |
---|---|---|---|---|
データ特性 | アクセス頻度が高い | よりアクセス頻度が低い | 最小限のアクセスでよい | アクセス頻度が 動的または予測不可能 |
主な用途 | コラボ、ファイル共有など | バックアップ、 災害対策など |
アーカイブ、 監査ログ保管など |
クラウドネイティブ、 AI アプリなど |
アクセス頻度 | 月に複数回 | 月に1回、 またはそれ以下 |
3ヶ月に1回、 またはそれ以下 |
使いたいときに 使いたいだけ |
最低保管期間 | なし | 30日 | 90日 | なし |
最低オブジェクトサイズ | なし | 128 KB | 256 KB | なし |
データ保管料金 | 高い | 普通 | 安い | 各月のアクティビティに基づいて Hot、Cool、Coldの Rateを自動割当て |
データ読出料金 | 無料 | 安い | 高い |
